AS10 (America Sport)

Model: AS10

GVWR: 1,880 lbs.

Main Frame: 2-Place / Tilt-Bed

Deck Dimensions: 101.5" x 10'

Axle: 2.2K Torsion EZ-Lube

Brakes: No

Tires: 18.5-8 LRC

Wheels: Silver E-Coated/5-4.5

Decking: 5/8" Marine Plywood

Frame Rail: Eagle America Custom Extrusion

Side Features: (See Exclusive Feature)

Cross-Members: 24" on Center /1.5" X 3" Aluminum Tube

Lighting: "LED" Sealed Beam

Wiring System: Custom Harness / 4-Flat

Security Connection: Safety Cables

Jack Stand: No - Optional

Hitch Mount: 2" Ball / Coupler

Deck Equipment: (2) Tie-Downs Bars w/ Sleeves

Overall Width: 102" w/ Exclusive Feature

Exclusive Feature: Use of Optional Side Accessories

Tire Upgrade: 20.5-10 LRC

Jack Option: Front Swivel w/Wheel

Side Accessories: Eagle America Side Tie-Downs (or) Stake Pockets

Spare Tire Carrier: U-Bolt Style
